YCB Series Gear Oil Pump

Material: Iron or Copper Alloy

YCB Series Gear Oil Pump used to delivery non-corrosive lubricating oil or similar liquid without Particle and fibers.

Temperature is not higher than 80 ℃, the viscosity is 5 * 10-6-1.5 * 10-3 m2 / s (5 to 1500 CST) nature of lubricating oil or other liquids, such as lubricating oil, and used in hydraulic transmission systems.

Type Capacity Speed Pressure NPSH Effciency Motor
m3/h r/min Mpa m % Hz kw
YCB0.6-0.6 0.6 910 0.6 5.5 60 50 0.75
1 1390 50 0.75
0.7 1130 60 0.75
1.2 1710 60 0.75
YCB0.6-1.6 0.6 910 1.6 7 70 50 1.1
1 1400 50 1.5
0.7 1130 60 1.1
1.2 1710 60 1.5
YCB1.6-0.6 1.6 910 0.6 5.5 63 50 0.75
2.5 1400 50 1.1
1.9 1130 60 1.1
3 1710 60 1.1
YCB1.6-1.6 1.6 940 1.6 7 71 50 2.2
2.5 1400 50 4
1.9 1150 60 2.2
3 1750 60 4
YCB3.3-0.6 3.3 940 0.6 5 60 50 1.5
5 1420 50 2.2
4 1150 60 1.5
6 1730 60 2.2
YCB3.3-1.6 3.3 960 1.6 7 72 50 5.5
5 1440 50 7.5
4 1170 60 5.5
6 1750 60 7.5
YCB4-0.6 4 940 0.6 5 60 50 1.5
6 1420 50 2.2
4.8 1150 60 2.2
7.2 1730 60 3
YCB4-1.6 4 960 1.6 7 72 50 5.5
6 1440 50 7.5
4.8 1170 60 5.5
7.2 1750 60 7.5
YCB8-0.6 8 960 0.6 5 61 50 3
12 1440 50 5.5
9.6 1170 60 4
14.4 1750 60 5.5
YCB8-1.6 8 970 1.6 7 75 50 11
12 1460 50 15
9.6 1170 60 11
14.4 1760 60 15
YCB10-0.6 10 960 0.6 5 62 50 4
15 1440 50 5.5
12 1170 60 5.5
18 1750 60 7.5
YCB10-1.6 10 970 1.6 7 76 50 11
15 1470 50 15
12 1170 60 11
18 1770 60 18.5
YCB20-0.6 20 970 0.6 5 68 50 7.5
24 1170 60 7.5
YCB25-0.6 25 970 0.6 5.5 69 50 11
30 1170 60 11
YCB30-0.6 30 970 0.6 5.5 65 50 11
36 1170 60 11
YCB40-0.6 40 970 0.6 5.5 66 50 15
48 1180 60 15

* Please contact us for final confirmation on above data before you place order.
